BALL BEARING TURNTABLES

In order to establish a rotatable connection between the bogie and the vehicle frame, ball pivot bearings or ball bearing turntables are required. Typical areas of application are truck trailers and agricultural vehicles. Ball bearing turntables can be swiveled 360 °, but in normal operation the swivel range is less than 180 °. A ball bearing assembly is primarily designed for axial loads. Radial loads occur to a small extent. They play a subordinate role on turntable chassis.
turntables are therefore not suitable for the operation of vehicles or applications with high radial loads or centrifugal forces!

Catalog »


Standard Product Range

Z-profile, U-profile, single- or double-ballrace

Series

Description

Brochure

HB Standard For full trailers, agricultural trailers, dumpers and special vehicles. PDF PROSPEKT: HB KUGELLENKKRäNZE IM DETAIL
HB Low-Maintenance For full trailers, agricultural trailers, dumpers and special vehicles, low-maintenance. PDF PROSPEKT: HB KUGELLENKKRäNZE IM DETAIL
HB Double Ball Race NEW! Turntables particulary suitable for heavy operating conditions. PDF PROSPEKT: HB KUGELLENKKRäNZE IM DETAIL
HB Heavy Duty Single & double ball race turntables in heavy duty. PDF PROSPEKT: HB KUGELLENKKRäNZE IM DETAIL
HB Slow Moving Vehicles For slow moving (max. 40 km/h) and industrial application. PDF PROSPEKT: HB KUGELLENKKRäNZE IM DETAIL
HB ZG Series Turntables with a Z-profile. PDF PROSPEKT: HB KUGELLENKKRäNZE IM DETAIL
HB ND Series Turntables with a Z-profile.
For slow moving (max. 40 km/h) and industrial application.
PDF PROSPEKT: HB KUGELLENKKRäNZE IM DETAIL
HB Double Ball Race - Low Maintenance - Forged
-Made in Germany-
Turntables with a U-profile.
For special requirements and high loads. -Made in Germany-
PDF PROSPEKT: HB KUGELLENKKRäNZE IM DETAIL

Installation and maintenance instructions >>


Ball bearing turntables with Z-profile

400 - 1100 mm

Ball bearing turntables - ZG Series (Z-profile) Art.-No. Onlineshop
HB 400L - 400 mm 34800200 kaufen
HB 500 ZG - 500 mm 34800010 kaufen
HB 650ZG - 650 mm 34800020 kaufen
HB 650N - 650 mm (Jost) 32400020 kaufen
HB 750 ZG - 750 mm 34800030 kaufen
HB 850 ZG - 850 mm 34800040 kaufen
HB 950 ZG - 950 mm 34800050 kaufen
HB 1050 ZG - 1050 mm 34800060 kaufen
HB 950 ND - 950 mm 34800460 kaufen
HB 1100 ND - 1100 mm 34800410 kaufen

Ball bearing turntables with U-profile

Standard: 1100 & 1200 mm  - [ HD = heavy duty ]

Ball bearing turntables - HB Standard Art.-No. Onlineshop
HB 1100/22 - 1100 mm 34300010 kaufen
HB 1100/22 HD - 1100 mm 34800090 kaufen
HB 1200/22 - 1200 mm 34300020 kaufen
HB 1200/22 HD - 1200 mm 34800100 kaufen


Ball bearing turntables - HB Low maintenance Art.-No. Onlineshop
HB 1200/22(W) - 1200 mm 34300030 kaufen
HB 1300/22(W) - 1300 mm 34300040 kaufen

Ball bearing turntables

low running  300 - 1050 mm

Ball bearing turntables - low running Art.-No. Onlineshop
HB 300/55 - 300 mm 19000220 kaufen
HB 400/55 - 400 mm 19000010 kaufen
HB 500/55 - 500 mm 19000020 kaufen
HB 1050/65 - 1050 mm 18900120 kaufen

SLEWING RING BEARINGS

Precision pivot bearings / - connections made of stainless steel!

Please note that our slewing ring bearings are not in stock.

It is to be expected a delivery time of 3-6 weeks (germany)

Please inquire here. »
